Inverter NOT Gate: 74HC05
$1.99
✅SHIPS TODAY
This chip includes 6 basic digital logic NOT gates / inverters. Each NOT gate takes in1 input and gives out the opposite output. Useful for inverting signals from HIGH to LOW or vice versa.
Security policy
(edit with the Customer Reassurance module)
Delivery policy
(edit with the Customer Reassurance module)
Return policy
(edit with the Customer Reassurance module)
Specifications:
- Basic NOT Gate IC / Inverter
- Operating Voltage: 2V - 6V
- 6 NOT Gates on-chip
- Pinout:
- NOT GATE Number 1:
- Pin 1: Input
- Pin 2: Output
- NOT GATE Number 2:
- Pin 3: Input
- Pin 4: Output
- NOT GATE Number 3:
- Pin 5: Input
- Pin 6: Output
- NOT GATE Number 4:
- Pin 9: Input
- Pin 8: Output
- NOT GATE Number 5:
- Pin 11: Input
- Pin 10: Output
- NOT GATE Number 6:
- Pin 13: Input
- Pin 12: Output
- Power:
- Pin 14
- Ground:
- Pin 7
